FBN-900 Ultrasonic Automatic Paper Cup Making Machine

FBN-900 Ultrasonic Automatic Paper Cup Making Machine

FBN-900 ULTRASONIC AUTOMATIC PAPER CUP MAKING MACHINE DESCRIPTION :

FBN-900 automatic paper cup making machine is multi- station automatic molding machine ,automatic paper feeding ,sealing ,bottom heating ,knurling ,crimping and continuous process of photoelectric detection and fault alarm,counting function ,is the ideal equipment for fast drink cup ,tea cup ,coffee cup ,advertising cup ,ice cream cups or other food containers for the production of paper cone.

FBN-900 ULTRASONIC AUTOMATIC PAPER CUP MAKING MACHINE TECHNICAL SPECIFICATION

Suitable cup size 2-9oz
Speed of machine 65-70pcs/min
Suitable Material of paper

135-280g/square miter

single PE face or double PE coated paper

Power required 380v 50hz or customized
Main power 5.5kw
Weight of machine 1.5TON
Size of machine 2300X1100X1600mm
Working pressure 0.4MPA
Air required 0.6M3/MIN (need buy air compressor extra)
Paper cup making machine can be customized according to different paper cup .

FBN-900 ULTRASONIC AUTOMATIC PAPER CUP MAKING MACHINE TECHNICAL FEATURES

1.HMI&PLC program control,easy operate and intelligent .(it is option,normal machine not have )
2.Sensor detects all running steps ,fault guide ,keep good quality paper cups and machine long life.
3.Good quality open type cam(8 divide)driver,easy maintenance ,stable and reliable
4.Good quality electric elements .long life .
5.Separate cam &rod driver the knurling .curling and heating parts .to keep machine stable and easy maintenance .
